Return Gas boilers

Wall-mounted boiler Evolution Visio

Hydromotrix Evolution Visio®

Power:    25 kW Heating mixed:
Instant or stored hot water (80l or 120l)
Chauffage Classe B
ECS Classe B
  • Wall-mounted boiler with natural draft
  • Available in natural gas CMV version
  • CMV gas outlet BAZ Pilot (controlled outlet) qualifies for Energy Saving Certificate
  • Class V control ECO RADIO SYSTEM Visio® (ŋ 3%)
  • Compatible with Frisquet Connect
Chauffage
Domestic Hot Water
Rendement-83 Seasonal settings

The top performing low-temperature boiler

Its power and compact size mean that this boiler can be installed both in an apartment where space is tight or in a larger residence.

For greater hot water needs, the Hydromotrix Evolution can be combined with a UPEC 80 or 120 litre tank, giving exceptional hot water supply.

Technical characteristics
A full range of equipment as standard

ECO RADIO SYSTEM VISIO® appliance • Radio communication satellite unit • FLATFIRE® burner • Electronic ignition • Gas ionization safety device • Dual electro-valve gas safety unit • Electronic overheating safety device • Electronic water level safety • Electronic frost-free safety unit • Expansion tank • 4-way motorised valve • Variable-speed low consumption circulator • Connectors for 2nd heating circuit • Anti-legionella programme • Automatic thermostat controller • Built-in hot water disconnection • Mineral wool heat insulation.

Power (kW) 25 30 UPEC 80 l UPEC 120 l
DHW flow rate (l/min) 12,5 14,5 20 24
seasonal efficiency
with regulation (%)
82 82 - -
Nox rate on PCS (mg/kWh) 51 54 - -
Height (mm) 795 915 795 915
Width (mm) 495 495 460 520
Depth (mm) 437 447 477 515
Weight under load (kg) 71 88 115 161
Expansion Tank (l) 11 12 - -
ø Fume outlets (mm) 125 139 - -

Frisquet Connect
your boiler obeys you at a distance

Manage your heating and hot water by controlling your Visio® boiler wherever you are, at home or away from home using your smartphone, tablet or computer. Download the Frisquet Connect app, or connect via the website frisquetconnect.

Accessories
Condensation Visio®

  • Frisquet Connect

  • H Visio module

  • Circuit connection kit for Visio H module

See all accessories
  • Circulator module

  • Solar relay kit for each boiler

  • Boiler back panel

  • Gas VMC renovation special

  • Outdoor sensor

  • CESI – Domestic solar water heater

  • Multi-function radio unit - swimming pool, alarm repeater, additional circulator

The quality of our boilers means we can offer you a manufacturer's warranty much longer than the legal requirement, our long-term warranty1. This warranty applies to all our products, including the renewable energy appliances, as long as their commissioning and maintenance is carried out by a professional.

  • 5 years : heating body, burner, combustion chamber, circulator and stainless steel tank, tank for solar UPEC tank, solar collector
  • 2 years : additional parts / other components
